How to connect any rover or machine-control system, and what to check when it will not fix.

NTRIP
RTCM 3
GDA2020 and GDA94
Your rover's settings

Four settings, and you're on corrections

Every rover and machine-control display asks for the same things, though the names vary. Enter these in its NTRIP or internet corrections settings.

Serveralso called Caster, Host or Address
ntrip.baselinertk.com
Port
2101
Mountpointalso called Stream
NEAREST_20 or NEAREST_94or one base by name: see below
Username and password
Your rover's loginshown in your account at app.baselinertk.com, one for each rover
Send positionalso called Send GGA or Send NMEA
On
NEAREST_20 / NEAREST_94

Nearest base, automatically

We send corrections from the base station closest to your rover, and move you to a closer one as you travel between sites. Your rover must send its position for this to work.

_20 or _94

Pick the datum

_20 sends GDA2020 and _94 sends GDA94. Use the one your design and site control are in: the two sit about 1.5 metres apart. For AHD heights, pair GDA2020 with AUSGeoid2020, and GDA94 with AUSGeoid09.

Ballarat_20

Or one base by name

Choose a base station by name to stay on it wherever you go. Your rover does not need to send its position. Once it has connected, its list shows the bases within 30 km, and any other base works if you type its name.

VIRTUAL_20 / VIRTUAL_94
Coming soon · December

Virtual Base, generated from your rover's position

For when you are not near a base. We build a base station from the base stations around you, so your base is right where you are working.

  • Turn on send position, the same setting as NEAREST.
  • VIRTUAL_20 sends GDA2020 and VIRTUAL_94 sends GDA94.
  • Same server, port and login as every other mountpoint.

Connected but no fix? Check these first.

  1. Check data is flowing. Look in the rover's modem or connection settings. You should see data being received, and a connection latency under 1 second.
  2. No data, or latency over a second? It is usually the modem or the mobile signal. Isolate the machine, wait a moment, then start it again.
  3. Check your login details. Server ntrip.baselinertk.com, port 2101, and the rover's own username and password from your account. The username and password are case sensitive.
  4. Still struggling? Email support@baselinertk.com with the rover's username and the mountpoint, and we will look at the connection from our end.

Connected but no fix? Check that send position is on, and that the mountpoint's datum matches your job. Still stuck? Email support@baselinertk.com and we will look at your connection from our end.

What it works with

Machine control

  • Trimble GCS900 CB450 / CB460
  • Trimble Earthworks TD510 / TD520
  • Cat Grade with 3D
  • Topcon 3D-MC MC-X, GX-55 / GX-75
  • Komatsu iMC intelligent Machine Control
  • Leica iCON / MC1

Survey rovers

  • Trimble Access R12i, R12, R10, R8s, R780, R980
  • Trimble Siteworks
  • Trimble DA2 Catalyst
  • Leica Captivate GS18 T, GS18 I, GS16, GS07
  • Topcon MAGNET Field HiPer VR, HiPer HR, HiPer SR
  • Sokkia GCX3 / GRX3
  • Emlid Reach RS2 / RS2+ / RS3 / RS4
  • Emlid Reach RX / RX2
  • CHCNAV i90 / i93
  • Stonex S900A / S980A

Farming

  • John Deere StarFire 6000 / 7000 / 7500, Gen 4 / G5 displays
  • Trimble ag GFX-750, GFX-1260, TMX-2050, Precision-IQ
  • Topcon ag X35 / X25, AGI-4
  • Case IH AFS AFS Pro 1200, AFS 372
  • New Holland PLM IntelliView, NH 372
  • Ag Leader GPS 7500 / 7000, InCommand
  • FJDynamics AT2
  • CHCNAV NX510 / NX612

DIY and hobby

  • ArduSimple simpleRTK2B / 3B
  • u-blox ZED-F9P boards
  • SparkFun RTK Facet
  • Septentrio mosaic-X5
  • ArduPilot Mission Planner, QGroundControl
  • Emlid Reach M2 / M+
  • Phone NTRIP apps Lefebure NTRIP Client, SW Maps

Not on the list? If it takes RTCM 3 corrections over NTRIP it should work. The 14-day free trial is the sure way to know, and if you tell us what you ran it on we will add it here.

Setup questions

What to check first.

What is Virtual Base?

A base station generated from your rover's own position. We build it from the base stations around you, so your base is right where you are working, even when you are a long way from any one station. It is coming in December, on the mountpoints VIRTUAL_20 for GDA2020 and VIRTUAL_94 for GDA94. Your rover sends its position, the same setting as NEAREST.

Do I need a SIM, and how much data does it use?

Yes. The machine needs internet: a SIM in its modem, or a phone hotspot. Corrections use about 5 MB an hour, about 50 MB in a ten-hour day. A base sending more satellite systems uses a little more.

Can two machines share a login?

No. Each rover needs its own login. Add rovers in Manage billing, and each new login appears in your account within a minute or so.

Which satellite systems are included?

GPS, GLONASS, Galileo, BeiDou and QZSS, where the base station sends them, as RTCM 3 corrections once a second. Your rover uses whichever of them it can track.

My rover connects but never gets a fix. What now?

Check data is flowing: in the rover's modem or connection settings you should see data being received, and a connection latency under 1 second. If not, it is usually the modem or the mobile signal, so isolate the machine, wait a moment, then start it again. Then check the server, port, username and password: the username and password are case sensitive. Still stuck? Email support@baselinertk.com and we will look at your connection from our end.

Does my rover need to send its position?

Yes, on the NEAREST mountpoints, and on VIRTUAL_20 and VIRTUAL_94 when Virtual Base arrives in December. Turn on "send GGA" or "send NMEA" in your rover's NTRIP settings: it is how we choose your base. A base picked by name does not need it.

What settings do I enter in my rover?

Server ntrip.baselinertk.com, port 2101, mountpoint NEAREST_20 for GDA2020 or NEAREST_94 for GDA94, and the username and password shown in your account. From December you can also use VIRTUAL_20 or VIRTUAL_94 for a Virtual Base.
