GDA94 or GDA2020

Which datum do I use?

GDA94 and GDA2020 are two versions of Australia's map grid. The continent moves north-east about 7 cm a year, so by 2020 the ground sat about 1.5 to 1.8 metres from where GDA94 put it, depending on where you are. GDA2020 moved the grid to match. Same ground, two sets of coordinates.

Use the wrong one and everything is out by about 1.5 metres.

Pick GDA94 if

  • your design file, site calibration or control sheet says GDA94 or MGA94;
  • the site's control was set up before about 2020 and has not been moved over;
  • the client or head contractor still works in GDA94.

Pick GDA2020 if

  • the design or control sheet says GDA2020 or MGA2020;
  • the job's design and control were set up new in GDA2020;
  • the client, council or road authority specifies GDA2020.

How to check in 30 seconds

  • The control sheet. The datum is printed on it, in the header or beside the coordinates: MGA94 or GDA94, MGA2020 or GDA2020.
  • A Trimble GCS900 or Earthworks site. The coordinate system belongs to the site's design files. Open the site's coordinate system or calibration and read the datum or zone name.
  • A known mark. Set up on a mark with known coordinates. About 1.5 metres out, with a good fix, means the wrong datum.

Still unsure? Email support@baselinertk.com with a photo of your control sheet and we will tell you which to use.

You choose by mountpoint

NEAREST_20 sends GDA2020. NEAREST_94 sends GDA94. Both are included for every rover, and you can change between them in your rover at any time. From December, VIRTUAL_20 and VIRTUAL_94 do the same for a Virtual Base, generated from your rover's position.

Two datums, one ground

Which one is yours?

Both describe the same ground. They differ because Australia has moved since GDA94 was set.
